FEATURES
- 6 Channels In, 8 Channels Out
- Channel Delay with steps of .02ms (1/4 inch)
- All settings are in Real Time
- External control with display presets
- USB + Bluetooth input to make adjustments via PC and APPs for Android Smart Phones and Tablets
- Low or High Level Input
- SP-DIF Digital Input Card Optical or Coax
- 4 Presets
- Completely manufactured in Italy
SPECIFICATIONS
| Input Mode: | Low Level {LL} / High Level {HL} |
| Input Imedance: | > 10Kohm [Typ 14.3Kohm] (LL) / 37ohm (HL) |
| Input Sensitivity: | 2Vrms ÷ 8Vrms (LL / 5Vrms ÷ 20Vrms (HL) – viaon-board potentiometers |
| Input Voltage Regulation: | -12dB ÷ 0dB – via on-board potentiometers |
| Max Output Signal: | 4Vrms |
| Output Imedance: | 50 ohm |
| S/N Ratio: | >102dB “A” (typ. 105dB “A”) |
| T.H.D. Distortion: | <-0.003% @ 1Vrms |
| Frequency Response: | 20Hz ÷ 20KHz (within -0.1dB) |
| Channel Separation: | >91dB (@ 100Hz) >91dB (@ 1KHz) >72dB (@ 10KHz) |
| Supply Voltage: | 11V ÷ 15V |
| Current Consumption: | 0.5A @ 12V |
| DC-DC Converter: | Transformer coupled, Voltage regulated, Current-Mode, Flyback converter |
| Conversion Frequency: | 105KHz |
| Ground Isolation vs Car Body: | 1Kohm (default) / Isolated (optional) / Grounded (optional) |
| Autosense: | Two operative modes (yes, High Level mode only) |
| Remote Output: | 130mA max |
| Communication Peripherals: | On-board USB, Bluetooth socket, Remote controller connector for optional display-control unit |
| Expansion Slot: | External Memory (EEprom) |
| Optical Board: | Optional |
