FEATURES:
- 8 channel input
- 12 channel output
- Digital input and output (Toslink)
- Coax input (RCA)
- Highest resolution, e.g. time delay in 0,02 msec/step
- All settings in real-time
- USB and optional BT adapter (MOS-BTM), for adjusting by PC, Android and BlackBerry (*) smart phone apps
- Low-Level or High-Level input with auto-sense (only by High-Level)
- Aux input with auto-sense for stereo signal
- Hands-free and mobile navigation
- 4 presets
- Mixer matrix to realize all possible mixtures and couple input and output channels as desired
- Intuitive User Interface and video tutorials to avoid an instruction book.
- Operating also without mouse, only with keys for an easy adjusting in the car
- DSP Technology made by cooperation MOSCONI-GLADEN
- Designed and made by MOSCONI, Italy
- Click here to download the latest version of the Software
(*) Compatible with all of the new BlackBerry 10 devices, Z10, Q10, and Q5.
Please note: that the BlackBerry 10 application is developed by a 3rd party developer not affiliated to Mosconi. For support, feature requests, updates, or other questions please contact the developer directly via BlackBerry World.
SPECIFICATIONS:
| Input Mode: | Low Level {LL} / High Level {HL} |
| Input Impedance: |
12Kohm (LL) / 47ohm (HL) |
| Input Sensitivity: |
1.2 – 8 Vrms (LL) / 3 – 20Vrms (HL) |
| Input Voltage Regulation: |
-16.5dB ÷ 0dB |
| Max Output Signal: | 8Vrms |
| Output Impedance: | 56 ohm |
| T.H.D. Distortion: | <0.003% @ 4Vrms |
| Frequency Response: |
10Hz-40Khz |
| Channel Separation: |
>90dB (@100Hz) |
| Supply Voltage: | 10V ÷ 16V DC |
| Autosense: | Off / BTL / SE |
| Remote Output: | 100mA max |
| Communication Peripherals: | USB, RCD/RC-Mini (optional), MOS-BTM (optional) |
| Size |
200x125x40mm (including fixed feet) |
